BK Series Power Supply

The BK Series Power Supply is a type of industrial or laboratory-grade power supply known for its reliability and versatility in providing stable electrical power. These power supplies are commonly used in testing, research, and development environments where precise control over voltage and current is essential. The BK Series typically includes features such as:

Adjustable Output: Users can finely adjust the output voltage and current to meet specific requirements.

High Efficiency: Designed for efficient power conversion, minimizing energy loss and heat generation.

Safety Features: Often includes overvoltage protection, overcurrent protection, and thermal shutdown to safeguard connected devices.

Multiple Outputs: Some models offer multiple output channels to power different devices simultaneously.

Digital Display: Clear readouts for voltage, current, and other parameters for easy monitoring.

Compact Design: Space-saving form factor suitable for benchtop use.

These power supplies are suitable for engineers, technicians, and hobbyists who need a reliable power source for various applications, from powering circuits to charging batteries.

Ref.	Model	Capacity(VA)	Voltage Combination	Case	Item Code
			Primary(V)/Secondary(V)	Qty.(Pcs)
	BK-40	40	440/220 240/24 220/24 220-380/110-60-48-24 380/220-110	24	02150040
	BK-60	50		24	02150060
	BK-100	100		16	02150100
	BK-160	160		12	02150160
	BK-250	250		6	02150250
	BK-400	400		6	02150400
	BK-630	630		4	02150630
	BK-800	800		4	02150800
	BK-1000	1000		1	02151000
	BK-1600	1500		1	02151600
	BK-2500	2500		1	02152500
	Note: Please mention the voltage combination when ordering. Other else multiple voltage combination upon request.
	Model Overall Dimension(mm) Mounting Dimension(mm) B Max D Max E Max A C E BK-40 78 72 90 56 46 4.6 BK-60 78 72 90 56 46 4.6 BK-100 85 88 96 64 62 4.6 BK-160 96 92 106 84 73.5 5.5 BK-250 96 100 106 84 85 5.8 BK-400 120 100 122 93 84 5.8 BK-630 150 114 140 125 92 7 BK-800 150 125 142 125 105 7 BK-1000 168 130 155 138 105 9 BK-1600 168 140 155 138 116 9 BK-2500 250 200 152 165 210 7
