PG 7 Cable Gland

P0707, P0707B, P0705, P0705B

• Our PG7 Nylon Cable Glands are designed with high mechanical strength and good toughness, ensuring excellent fatigue resistance and a high softening point. The smooth surface and low friction coefficient contribute to their wear resistance. Additionally, these glands offer excellent electrical properties, making them ideal for a wide range of applications.


For other materials or colors, please inquire! O-ring pre-installed by default!

Material Parameters

• Material: Made of UL-recognized nylon material
• Waterproof Ring: EPDM (optional NBR, silicone rubber, TPV, etc.)
• O-Ring: EPDM (optional silicone rubber, TPV, fluororubber, etc.)
• Operating Temperature: -40℃ to 100℃
• Color Options: Gray, black, other colors can be customized
• Material Options: V0 or F1 can be customized

Product Parameters

PG7

• Cable Diameter Range: 3-6.5 mm
• Height H: 21 mm
• Thread Length GL: 8 mm
• Wrench Size: 15 mm
• Product Model RAL7035: P0707
• Product Model RAL9005: P0707B

PG7

• Cable Diameter Range: 2-5 mm
• Height H: 21 mm
• Thread Length GL: 8 mm
• Wrench Size: 15 mm
• Product Model RAL7035: P0705
• Product Model RAL9005: P0705B
